Thermal Insulation Barrels

Density:1.2–1.3g/cm³

Max Working Temp:≥1600℃

Usage:for photovoltaic growth furnaces

Product Detail | Packaging

Product Detail

Shanghai Mac Corporation is a leading Thermal Insulation Barrels manufacturer and supplier.

Thermal Insulation Barrels (Insulation Shields) are high-performance thermal insulation components designed for photovoltaic growth furnaces. They deliver stable high-temperature performance, reduce energy consumption, and improve ingot yield.

If you want to know more about our Thermal Insulation Barrels products or price, please feel free to contact us,we will reply you within 24 hours.

Density:1.2–1.3g/cm³
Bending Strength:60–80MPa
Tensile Strength:80–90MPa
Shear Strength:10–15MPa
Compressive Strength:80–90MPa
Operating Temperature:≥1600℃

Superior Insulation: Low thermal conductivity cuts furnace heat loss and power consumption.
High-Temp Stability: Withstands repeated thermal shocks without cracking.
High Purity: Low ash content prevents silicon melt contamination.
Customizable: Available in full or segmented designs.

PV monocrystalline silicon furnaces
Polycrystalline ingot cast furnaces

Packaging of Thermal Insulation Barrels

Shanghai Mac products are packed and labeled according to the regulations and customer's requests. Great care is taken to avoid any damage which might otherwise be caused during storage or transportation.
